SS304 · SS316 · MS storage tanks for chemical, pharmaceutical, food & water treatment industries. 500L to 200,000L. Custom-built. ISO 9001 certified. Bhiwadi, Rajasthan (Delhi NCR).
Every tank is fabricated to your exact specifications — capacity, orientation, material, fittings and surface finish. Serving North India and beyond.
Cost-effective heavy-duty tanks for chemical, industrial and water storage. Carbon steel construction built to IS 803 and ASME standards.
Hygienic, corrosion-resistant tanks for food, beverage, pharma, dairy and mild chemical applications. Mirror polished interiors available.
Premium molybdenum-alloyed tanks for aggressive chemicals, API pharma, and chloride environments. Maximum corrosion resistance.
Use our free tank capacity calculator to size your tank and get an instant volume and plate weight estimate. Unsure which grade? Read our SS 304 vs SS 316 selection guide.
| Parameter | MS Tanks | SS 304 Tanks | SS 316 / 316L Tanks |
|---|---|---|---|
| Material Grade | IS 2062 Gr B / ASTM A36 | ASTM 304 / 304L | ASTM 316 / 316L |
| Capacity Range | 500L – 2,00,000L | 200L – 1,00,000L | 100L – 50,000L |
| Orientation | Vertical / Horizontal | Vertical / Horizontal | Vertical / Horizontal |
| Bottom Type | Flat / Conical / Dished | Flat / Conical / Dished | Flat / Conical / Dished |
| Design Pressure | Atmospheric to 10 bar | Atmospheric to 10 bar | Atmospheric to 16 bar |
| Design Code | IS 803 / ASME Sec VIII | IS 803 / ASME Sec VIII | ASME Sec VIII Div. 1 |
| Internal Surface Finish | Epoxy Painted / FRP Lined | 2B / Brushed / Mirror Polish | Mirror Polish / Electropolished |
| Insulation | Mineral Wool / PUF | PUF / Mineral Wool | PUF / Mineral Wool |
| NDT / Testing | Hydrostatic / UT / RT | Hydrostatic / Dye Penetrant | Hydrostatic / DP + Passivation |
| Typical Applications | Chemicals, Water, Fuel, Effluent | Food, Beverages, Dairy, Pharma | APIs, Harsh Chemicals, Pharma |
No standard sizes. Every tank built to your exact dimensions, fittings, and process requirements.
Quality management system ensures every tank meets or exceeds specified standards and tolerances.
Thousands of tanks delivered across India and internationally since 1987. Proven reliability.
Our Bhiwadi facility serves Delhi NCR clients with the fastest lead times in North India.
From aggressive chemical storage to hygienic food-grade tanks, our vessels perform reliably in the most demanding environments.
Reta Engineering Works is one of the few SS and MS storage tank manufacturers in India with its own fabrication plant in the Delhi NCR industrial belt (Bhiwadi). Being close means faster site visits, shorter transport and quicker delivery than distant fabricators. We design, fabricate and deliver stainless steel and mild steel storage tanks to chemical, pharma, food and water treatment plants across North India.
Planning a tank? Work out volume and shell thickness with our free tank capacity & thickness calculator, compare grades in the SS 304 vs SS 316 vs MS material guide, or see our SS 304 tanks, SS 316 tanks, mixing vessels and reactors.
We manufacture mild steel (MS) tanks, SS304 tanks, SS316/316L tanks, vertical and horizontal tanks, cone-bottom tanks, chemical storage tanks, pharmaceutical tanks, water tanks, fuel storage tanks, and custom-designed industrial vessels in any size or configuration.
We manufacture from 500 litres to 2,00,000 litres (200 KL / 200 cubic meters). Very large field-erected tanks above 200KL can be discussed. Custom sizes available for all materials.
SS304 is standard stainless steel — ideal for food, beverages, water and mild chemicals. SS316 contains added molybdenum giving it superior resistance to chlorides, strong acids and harsh corrosive chemicals, making it the choice for pharmaceutical APIs and aggressive process chemicals. SS316L is low-carbon SS316 for weld-intensive fabrication.
Yes. We manufacture GMP-compliant pharmaceutical tanks in SS316L with mirror-polished internals (Ra ≤ 0.5 µm), electropolished surfaces, sanitary tri-clamp fittings, and full documentation including material test reports, surface roughness certificates, and passivation records.
Yes. Our Bhiwadi, Rajasthan facility is in the heart of the Delhi NCR industrial belt. We supply tanks to Delhi, Gurugram, Noida, Faridabad, Manesar, Neemrana, Bawal, Alwar, Jaipur and across all of North India — faster, cheaper and with better service than distant fabricators.
Use our free tank capacity and thickness calculator. It works out the volume of vertical and horizontal tanks with flat, dished, ellipsoidal or torispherical heads, and estimates shell thickness by the ASME Section VIII Div 1 and API 650 methods. Send us the result and our engineers will confirm the design and quote within 24 hours.
We design to the standard your project needs: such as Indian Standards (IS) and API 650 for atmospheric storage tanks, and ASME Section VIII Div 1 methods for pressure-rated vessels. Material test certificates for the plates can be supplied with your tank.
